Accu-Chek Guide

Item Description

The Accu-Chek Guide meter offers cleverly designed solutions to help make blood glucose testing easier. Proven accuracy1,2,3 gives you result you can trust, along with spill-resistant test strip vial making strip removal easier. Plus, a strip port light, wide test strip dosing area and strip ejector button help take the hassle out of everyday testing.4



References:
1. ISO 15197:2013.
2. Accu-Chek Guide Test Strip package insert.
3. Brazg, RL., et al., J Diabetes Sci Technol 2016, Vol. 10(6) 1414–1415.
4. Harvey, C., et al., J Diabetes Sci Technol, 10(5): 1136-1141.

EASY

No coding

FAST

Results in less than 4 seconds

SAMPLE

Tiny: 0.6µL

STRIP PORT LIGHT

Allow testing in the dark

STRIP EJECTOR

Remove used strip in hygienic way

APP

Wireless connection to your mobile device

Benefits and Features
  • Proven accuracy that exceeds current ISO 15197:2013
  • Wide test strips dosing area —apply a small drop of blood anywhere along the wide yellow edge
  • The spill resistant vial helps you remove one strip at a time
  • Blood glucose readings in less than 4 seconds
  • Monitor in all light conditions, thanks to a bright, backlit display and a strip port light
  • Eject used test strips from the meter with the push of a button
  • Enjoy virtually pain free lancing with the included Accu-Chek Softclix lancing device2

References:
1. Accu-Chek Guide Test Strip Package Insert 2016. Kocher, S., et al., J Diabetes Sci Technol 2009 Sep 1; 3(5):1136-1143

Additional Specification
Measuring principle:

FAD dependent glucose dehydrogenase (GDH)

Measuring time:

Less than 4 seconds

Measuring conditions:

Temperature: 4°C to 45°C

Memory capacity:

720 blood glucose results and 32 control tests results with time and date

Test averages:

7, 14, 30 and 90 days

Data transfer:

Bluetooth (with mobile devices)

Micro USB cable (with computer)

Dimensions:

80 x 47 x 20 mm (L x W x H)

Weight:

Approx. 40g (with batteries)

Display:

LCD

Battery:

2 batteries, 3V lithium batteries type CR 2032

Auto power off:

90 seconds

Under dosing detection:

Yes

Altitude independence:

0 to 3,094 m (0 to 10,150 ft.)

Sample size:

0.6 µL

Measuring range:

10 - 600 mg/dL (0.6 – 33.3 mmol/L)

Sample types:

Capillary, venous, arterial and neonate (Venous, arterial and neonatal blood testing is limited to healthcare professional use.)

Sample dosing:

Capillary fill function

Hematocrit range:

10–65%

Test strip stability:

Test strips remain stable up to expiry date printed on test strip vial, even after opening (test strip container must be closed tightly after each test strip is removed)

How to use Accu-Chek Guide blood glucose meter

Get results in 3 steps:

  1. Insert your test strip into the meter and it turns on automatically.
  2. Apply your blood sample to the easy to see yellow dosing area. Only 1 small drop is needed.
  3. In less than 4 seconds, your test results will appear in the easy to read display.
